PremiumThe CRS-1000 is a reliable 1000W DC/DC converter series with a compact and robust design. It delivers 1000W at 24, 48, 72 and 110V and offers a great variety of input-ouput combinations. This converter series also allows for parallel connection. In addition, it offers options such as ORing FET, hold up time of 10ms, active protection against input reverse polarity, active inrush current limiter, and different cooling options (fan, fan redundancy, convection and conduction cooling).
The CRS-1000 has been designed with mounting brackets to be installed on a chassis and exhibits a closed anodized aluminum housing. Models in this series offer up to 94% efficiency at full load depending on input/output.
Looking for a CRS-1000 with different technical features? Tell us your challenge and we’ll make it ours from now on!
3 years for industrial version
5 years for railway version
| CRS-1000 | 24 VIN 14.4 … 30V | 36 VIN 21,6V ... 45V | 48 VIN 28.8 … 60V | 72 VIN 43.2 … 90V | 110 VIN 66 … 144V |
|---|---|---|---|---|---|
| 24Vout | CRS-1000-6475 / 1000W | CRS-1000-6487 / 1000W | CRS-1000-6478 / 1000W | CRS-1000-6481 / 1000W | CRS-1000-6484 / 1000W |
| 48Vout | CRS-1000-6476 / Check availability | CRS-1000-6488 / Check availability | CRS-1000-6479 / Check availability | CRS-1000-6482 / Check availability | CRS-1000-6485 / 1000W |
| 72Vout | CRS-1000-6490 / 1000W | CRS-1000-6491 / 1000W | Available upon request / Disponible bajo petición | Available upon request / Disponible bajo petición | CRS-1000-6494 / 1000W |
| 110Vout | CRS-1000-6492 / 1000W | Available upon request / Disponible bajo petición | Available upon request / Disponible bajo petición | Available upon request / Disponible bajo petición | CRS-1000-6493 / 1000W |
– ORing FET option
– High input-output isolation
– Adjustable output voltage
– Remote sensing
– Remote inhibit
– Input & Output OK LEDs
– Output failure alarm
– Input reverse polarity protection
– Different cooling options
– According to the standard EN50155
– Fire and smoke: EN45545-2 approved
– Efficiency up to 94%
PRODUCT WARRANTY
– 3 years for industrial version
– 5 years for railway version
The CRS-1000 DC/DC converter series fits in a wide range of industrial applications that require high wattage, and has been designed according to EN50155 for railway and transportation systems.
At Premium we offer to possibility to modify the CRS-1000 to each project´s needs to make it the best solutions for each application. Flexibility and customization is our standard, so don’t hesitate to contact us and tell us about your project.
Premium manufactures all units in Barcelona under strict quality controls.
